Modular Reed Bed

The Modular Reed Bed (MRB) is a self contained reed bed system that has integral settlement and sludge management. Every unit has a balancing section at the front to capture non-degradables and allow access to the inlet for maintenance, it then has a void zone where sludge pipework is fitted to capture up to 70% of the gross solids that enter the system. This addition of settlement prior to the biological reed bed portion means the units are perfect for storm treatment, it also means solids can be removed from the beds avoiding media blinding over time. The MRB is much easier to maintain than traditional systems and is relatable for ops teams who need to manage the process. Each unit is 3mx10m and they can be banked up for higher flows. A single unit will hydraulically take up to 7l/s and treat effectively up to 2l/s though aeration can be added to improve treatment capabilities.
